1. Dough kneading machine is one of the main noodle processing equipment, it is mainly used for kneading and pressing different kinds of soft or hard toughness dough for making dumpling wrapper, steamed bun wrapper, steamed stuffing bu wrapper and others.
2. It is unique technology double helix mechanissm can finish conveying dough -folding dough sheet-kneading and pressing automatic ans continuous. Stainless steel material, high -density scraper, pure copper motor, double sprocket, with timing function.
3. It is widely used in the unit dining room, restaurant, hotel, pasta processing unit and the household of individual business to process bread, strips, etc.
4. Working principle: Put the quantitative dough on down conveyor belt, start the machine, machine can finish conveying dough-folding sheet-kneading and pressing automatic and continuous.
|
Type |
JY-350 |
JY-500 |
|
Dough sheet thickness |
5-25mm |
8-25mm |
|
Dough sheet width |
350mm |
500mm |
|
Roller speed |
74r/min |
79r/min |
|
Rated input power |
2.2kw |
3kw |
|
Rated voltage |
380V 3~ |
380V 3~ |
|
Rated frequency |
50Hz |
50Hz |
|
General v belt |
A1219-3 |
A1473-3 |
|
Motor power |
2.2kw |
3kw |
|
Waterproof grade |
IPX1 |
IPX1 |
|
Machine dimension |
1035*650*1065mm |
1130*755*1240mm |
|
Machine weight |
245kg |
330kg |
|
Conveyor belt size |
Down belt: 1815*335mm Up belt: 945*370mm |
Down belt: 2066*480mm Up belt: 1222*460mm |
